Home Battery & Inverter Inverter Hoymiles 11.5kW Grid-Tied Inverter Split-phase AC-coupled Inverter | 120V 240V | MPPT | 10 Year Warranty

Hoymiles 11.5kW Grid-Tied Inverter Split-phase AC-coupled Inverter | 120V 240V | MPPT | 10 Year Warranty

In stock
SKU: HYS-11.5LV-USG1
  • Max. Efficiency 97.6%, CEC Efficiency 97.0%
  • Double MPPT tracker, up to 32A MPPT current
  • DC/AC ratio up to 150%
  • Ultralight for easy installation and space-saving
  • Support 120/240V backup power without external autotransformer
  • Seamless backup power for whole home or critical loads
  • Built-in dry contact flexibly set to earth fault alarm, load control or generator control
  • Integrated arc fault protection and rapid shutdown function

Mechanical Data:

  • Dimensions (WxHxD)inches: 19.8 Γ—29.1 Γ—7.95 inch
  • Weight: 90.4 lbs (41 kg)
  • Mounting: Wall Mounting
  • Operation Temperature (℉): -13 to +149 (> 113, derating)
  • Communication with BMS: RS485, CAN
  • Communication with Meter: RS485
  • Communication Interface: RS485, Wi-Fi/Ethernet/4G (optional)
  • Cooling: Natural convection
  • Max Parallel: 10

10 Year Warranty

$2,999.00
Sale $3,999.00 $2,999.00
Enroll Our Installer Program for 25%-50% Discount
